CrystalView DVI Plus
Fiber Extender - Dual-link DVI/USB 2.0
- Extends DVI video keyboard/mouse up to 1,300' (400m) over multi-mode cable
- Uncompressed single-link DVI to 1920 x 1200 and dual-link DVI to 2560 x 2048
- Supports USB keyboard/mouse
- Optional USB 2.0, serial, stereo speakers, and microphone
Typical Application
Overview
CrystalView DVI Plus provides extension of the highest quality video available on the market. The uncompressed video format avoids possible video corruption and frame drops normally associated with compressed video, providing smooth high definition video up to 1,300 feet over 50/125µ multi-mode fiber cabling.
CrystalView DVI Plus extender is produced in two models:
- The single-link DVI model supports resolutions of up to 1920 x 1200 @ 60Hz
- The dual-link DVI model works on two video cards in a CPU and supports resolutions of up to 2560 x 2048 @ 60Hz
Both models support only multi-mode fiber cables. USB 2.0 transparent is optional and supports any kind of USB peripheral, including scanners, printers, etc. CrystalView DVI Plus allows the connection of two monitors with one KVM station. Stereo audio is also optionally available.
Specifications ▼
| Dimensions (W x D x H) | 5.2" x 7.1" x 1.7" (133 x 180 x 43 mm) |
| Weight | 2.6 lbs (1.2 kgs) |
| Power | 90-240 VAC 50-60Hz External adapter, +5V DC, 2A 5W |
| Distance | 1920 x 1200 (single link): 1000' (300m) 2560 x 2048 (dual-link): 1000' (300m) |
| Connectors | Transmitter: DVI video: DVI female USB keyboard/mouse: USB Type B PS/2 keyboard/mouse: Two PS/2 mini-din6F Audio: Two 3.5mm stereo jacks Serial: DB9F Link: RJ45 jack, one per video port Receiver: DVI video: DVI female USB keyboard/mouse: Two USB type A jack PS/2 keyboard/mouse: Two PS/2 mini-din6F Audio: Two 3.5mm stereo jacks Serial: DB9M Link: RJ45 jack, one per video port Power: Barrel jack |
| Controls | Unit power: Red LED Video status: Green LED per port |
| Environment | Operating temperature: 41°F–113°F (5°C–45°C) Storage temperature: -13°F–140°F (-25°C–60°C) Relative humidity: 0%–80%, non-condensing |
Part numbers ▼
| Kits (transmitter, receiver, and power supply) | |
|---|---|
| CRK-1DFMT1SL | Single Link, Digital Fiber KVM Extender, Single-head Video, DVI, USB 2.0 |
| CRK-1DFMT2SL | Single Link, Digital Fiber KVM Extender, Dual-head Video, DVI, USB 2.0 |
| CRK-1DFMT1DL | Dual-link, Digital Fiber KVM Extender, Single-head Video, DVI, USB 2.0 |
| CRK-1DFMH1SL | Single Link, Digital Fiber KVM Extender, Single-head Video, DVI, HID |
| CRK-1DFMH2SL | Single Link, Digital Fiber KVM Extender, Dual-head Video, DVI, HID |
| CRK-1DFMH1DL | Dual-link, Digital Fiber KVM Extender, Single-head Video, DVI, HID |
| /AUD | Audio option for kit |
